RAL Colors

ChromaSpot uses an unofficial RAL color library measured with an X-Rite i1Pro3 spectrophotometer from official samples. We decided to eliminate most of the metalized and fluorescent samples on the list, as I1Pro 3 was not designed to measure them. Numeric data do not correspond to visual perception, and metalized samples require either multi-angle or spherical instruments. We are working on a dedicated metalized samples library. Visual appearance is significant; therefore, we should not mix regular matt samples with special effects.
Data are the same under all measurement conditions, and no fluorescence phenomena exist. The closest Chromaspot color sample was assigned to RAL color in the next step.|

Due to the homogeneity rules, not all RAL samples are addressed with a unique ChromaSpot code.

There are 4 cases reported below:

RAL	ChromaSpot	∆E2000	∆E2000 (inside RAL)
RAL 1007	8Y2.69	1.1	1.75
RAL 1037	8Y2.69	1.2	1.75
RAL 3000	6R4.37	2.1	2.5; 3.3; 4.5
RAL 3013		1.1
RAL 3016		3.5
RAL 5005	3V3.24	1.9	1.4
RAL 5010	3V3.24	1.4	1.4
RAL 7011	0B5.38	1.4	2.4
RAL 7012	0B5.38	1.1	2.4

The explanation is simple: if the ChromaSpot sample is halfway through two RAL colors relatively close to one another, there is no unique transformation.

ChromaSpot has more than 4000 samples, and it makes no practical sense to add twice more just to reduce deviation for virtually any color system transformation.

RAL Sample names adoption

We decided to adopt RAL names initially and vote on this decision later. It seems to be practical to use the same name for very close samples in both systems.

ChromaSpot	RAL	English	∆E
3Y4.74	RAL 1000	Green beige	2.3
3Y2.73	RAL 1001	Beige	2.4
4Y3.73	RAL 1002	Sand yellow	1.9
9Y3.73	RAL 1003	Signal yellow	2.4
8Y2.73	RAL 1004	Golden yellow	1.8
7Y3.66	RAL 1005	Honey yellow	2.1
8Y2.67	RAL 1006	Maize yellow	2.0
8Y2.69	RAL 1007	Daffodil yellow	1.1
3Y1.58	RAL 1011	Brown beige	2.6
6Y3.73	RAL 1012	Lemon yellow	0.3
1Y3.88	RAL 1013	Oyster white	1.3
2Y3.81	RAL 1014	Ivory	0.5
2Y3.87	RAL 1015	Light ivory	1.5
7Y4.91	RAL 1016	Sulfur yellow	2.4
6Y2.75	RAL 1017	Saffron yellow	2.3
7Y3.86	RAL 1018	Zinc yellow	0.7
1Y2.62	RAL 1019	Grey beige	2.6
2Y4.60	RAL 1020	Olive yellow	1.5
9Y3.79	RAL 1021	Colza yellow	1.0
9Y3.80	RAL 1023	Traffic yellow	2.0
4Y3.63	RAL 1024	Ochre yellow	1.5
6Y4.54	RAL 1027	Curry	2.9
9Y2.77	RAL 1028	Melon yellow	1.1
7Y2.74	RAL 1032	Broom yellow	1.9
8Y1.77	RAL 1033	Dahlia yellow	2.7
5Y1.73	RAL 1034	Pastel yellow	1.5
8Y1.61	RAL 2000	Yellow orange	1.4
7R5.51	RAL 2001	Red orange	2.3
6R5.48	RAL 2002	Vermilion	3.4
8R6.67	RAL 2003	Pastel orange	1.4
9R6.58	RAL 2004	Pure orange	1.0
7R6.61	RAL 2008	Bright red orange	2.0
9R6.58	RAL 2009	Traffic orange	1.3
7R6.56	RAL 2010	Signal orange	1.1
8R6.63	RAL 2011	Deep orange	1.3
6R5.58	RAL 2012	Salmon orange	0.8
6R5.34	RAL 3001	Signal red	2.8
6R4.35	RAL 3002	Carmine red	1.1
6R4.30	RAL 3003	Ruby red	1.4
4R3.23	RAL 3004	Purple red	1.9
3R2.20	RAL 3005	Wine red	1.9
1R2.18	RAL 3007	Black red	2.0
3R4.30	RAL 3009	Oxide red	1.7
4R4.28	RAL 3011	Brown red	1.4
3R5.61	RAL 3012	Beige red	1.7
6R4.37	RAL 3013	Tomato red	1.1
3R2.59	RAL 3014	Antique pink	2.1
2R2.70	RAL 3015	Light pink	1.4
6R3.54	RAL 3017	Rose	2.4
6R3.51	RAL 3018	Strawberry red	2.0
7R4.40	RAL 3020	Traffic red	2.3
5R4.56	RAL 3022	Salmon pink	0.9
6R3.40	RAL 3027	Raspberry red	0.7
7R4.45	RAL 3028	Pure red	3.2
5R3.38	RAL 3031	Orient red	2.0
2P4.44	RAL 4001	Red lilac	1.5
4R2.36	RAL 4002	Red violet	1.0
4P6.54	RAL 4003	Heather violet	2.4
3R2.23	RAL 4004	Claret violet	2.5
3P2.47	RAL 4005	Blue lilac	1.9
4P5.37	RAL 4006	Traffic purple	1.3
2P5.20	RAL 4007	Purple violet	2.7
4P4.40	RAL 4008	Signal violet	1.2
1P6.55	RAL 4009	Pastel violet	2.2
6R1.47	RAL 4010	Telemagenta	2.4
2V3.32	RAL 5000	Violet blue	2.3
2V1.26	RAL 5001	Green blue	2.2
4V5.20	RAL 5002	Ultramarine blue	1.1
2V3.15	RAL 5003	Saphire blue	2.4
1V4.04	RAL 5004	Black blue	2.6
2V2.42	RAL 5007	Brillant blue	2.7
1V1.18	RAL 5008	Grey blue	2.4
2V1.34	RAL 5009	Azure blue	1.3
3V3.24	RAL 5010	Gentian blue	1.4
1V4.12	RAL 5011	Steel blue	1.3
3V1.48	RAL 5012	Light blue	1.8
2V4.15	RAL 5013	Cobalt blue	1.4
1V2.47	RAL 5014	Pigeon blue	2.1
4V2.45	RAL 5015	Sky blue	2.2
4V2.30	RAL 5017	Traffic blue	0.7
3B3.50	RAL 5018	Turquoise blue	1.4
3V2.31	RAL 5019	Capri blue	1.8
2B5.19	RAL 5020	Ocean blue	0.9
3B3.43	RAL 5021	Water blue	2.8
3V6.16	RAL 5022	Night blue	1.4
2V3.43	RAL 5023	Distant blue	2.7
2V1.56	RAL 5024	Pastel blue	1.2
2G6.41	RAL 6000	Patina green	2.1
4G3.39	RAL 6001	Emerald green	1.9
3G3.36	RAL 6002	Leaf green	2.7
1Y6.31	RAL 6003	Olive green	2.6
2B3.23	RAL 6004	Blue green	1.8
2G6.20	RAL 6005	Moss green	1.8
0Y5.23	RAL 6006	Grey olive	3.0
1G1.20	RAL 6007	Bottle green	1.1
1Y4.18	RAL 6008	Brown green	1.9
1G4.17	RAL 6009	Fir green	2.7
4G2.43	RAL 6010	Grass green	2.6
2G2.48	RAL 6011	Reseda green	2.0
1G6.22	RAL 6012	Black green	2.7
1Y5.48	RAL 6013	Reed green	1.6
1Y4.25	RAL 6014	Yellow olive	1.9
0G1.25	RAL 6015	Black olive	1.6
3G6.36	RAL 6016	Turquoise green	1.1
4G2.49	RAL 6017	May green	1.6
5G2.58	RAL 6018	Yellow green	1.5
2G2.77	RAL 6019	Pastel green	1.9
1G2.26	RAL 6020	Chrome green	2.7
1G2.61	RAL 6021	Pale green	1.6
1Y3.19	RAL 6022	Olive drab	1.4
4G5.47	RAL 6024	Traffic green	2.1
3G1.45	RAL 6025	Fern green	2.1
3B1.31	RAL 6026	Opal green	0.7
2B2.68	RAL 6027	Light green	2.6
1G6.31	RAL 6028	Pine green	0.6
5G5.38	RAL 6029	Mint green	1.5
4G5.47	RAL 6032	Signal green	2.4
2B2.47	RAL 6033	Mint turquoise	2.4
2B2.66	RAL 6034	Pastel turquoise	2.0
7G3.49	RAL 6037	Pure green	2.2
1V1.53	RAL 7000	Squirrel grey	2.1
0V2.63	RAL 7001	Silver grey	2.3
1Y3.53	RAL 7002	Olive grey	3.0
0Y4.48	RAL 7003	Moss grey	1.8
N.63	RAL 7004	Signal grey	1.4
0G3.46	RAL 7005	Mouse grey	1.2
1Y1.44	RAL 7006	Beige grey	2.6
2Y2.44	RAL 7008	Khaki grey	2.5
1G2.36	RAL 7009	Green grey	2.3
0G2.36	RAL 7010	Tarpaulin grey	1.6
0B5.38	RAL 7012	Basalt grey	1.1
1Y3.31	RAL 7013	Brown grey	3.0
0V2.33	RAL 7015	Slate grey	1.7
0B5.26	RAL 7016	Anthracite grey	2.3
0B6.19	RAL 7021	Black grey	1.5
0Y3.28	RAL 7022	Umbra grey	1.5
0Y5.53	RAL 7023	Concrete grey	2.2
0V4.30	RAL 7024	Graphite grey	1.4
0B2.25	RAL 7026	Granite grey	2.5
0Y5.59	RAL 7030	Stone grey	0.8
0B6.40	RAL 7031	Blue grey	1.8
1Y4.70	RAL 7032	Pebble grey	2.0
1G1.55	RAL 7033	Cement grey	2.6
1Y4.55	RAL 7034	Yellow grey	2.6
0G2.78	RAL 7035	Light grey	0.9
0R1.61	RAL 7036	Platinum grey	2.1
0B2.51	RAL 7037	Dusty grey	1.6
0Y6.70	RAL 7038	Agate grey	0.9
0Y3.47	RAL 7039	Quartz grey	2.2
0V2.63	RAL 7040	Window grey	1.3
N.61	RAL 7042	Traffic grey A	2.0
0B2.34	RAL 7043	Traffic grey B	1.2
0Y3.75	RAL 7044	Silk grey	2.0
0V3.60	RAL 7045	Telegrey 1	2.1
0V2.55	RAL 7046	Telegrey 2	1.3
N.78	RAL 7047	Telegrey 4	0.9
3Y2.44	RAL 8000	Green brown	2.5
4Y1.47	RAL 8001	Ochre brown	2.3
2R5.38	RAL 8002	Signal brown	2.1
3Y1.35	RAL 8003	Clay brown	2.3
4R5.41	RAL 8004	Copper brown	1.6
2R6.31	RAL 8007	Fawn brown	0.8
3Y1.36	RAL 8008	Olive brown	1.1
2R6.26	RAL 8011	Nut brown	1.7
3R5.24	RAL 8012	Red brown	2.2
2Y1.21	RAL 8014	Sepia brown	2.6
2R4.23	RAL 8015	Chestnut brown	1.6
2R5.22	RAL 8016	Mahogany brown	0.8
1R5.20	RAL 8017	Chocolate brown	2.0
0R3.21	RAL 8019	Grey brown	0.8
0R2.07	RAL 8022	Black brown	1.8
5R6.47	RAL 8023	Orange brown	0.5
2R6.40	RAL 8024	Beige brown	1.6
1R6.39	RAL 8025	Pale brown	1.6
1Y1.26	RAL 8028	Terra brown	1.6
1Y3.91	RAL 9001	Cream	1.1
0Y5.85	RAL 9002	Grey white	0.1
0Y2.94	RAL 9003	Signal white	1.6
N.11	RAL 9004	Signal black	1.1
N.05	RAL 9005	Jet black	1.1
N.63	RAL 9006	White aluminium	1.6
N.52	RAL 9007	Grey aluminium	1.9
0Y4.91	RAL 9010	Pure white	1.6
0V4.12	RAL 9011	Graphite black	2.1
0G1.90	RAL 9016	Traffic white	1.9
N.08	RAL 9017	Traffic black	1.0
0G3.84	RAL 9018	Papyrus white	1.8

The average ∆E00 difference for this transformation is 1.8
